1288w Duty - Coldroom Max Volume 9.5m3.
Capacity at room temp 0c / 32oc ambient
The Rivacold Blocksystem is contained in one housing, consisting of a condensing unit, evaporator and an electrical control panel. This solution enables the product to be easily installed, with compact overall dimensions and reduced maintenance costs.
The SFM range enables the optimum use of the total cold room volume. They are equipped with a remote electrical control panel with a cable length of 5 m. Capillary expansion. (Optional thermostatic expansion valve). Off cycle defrosting (HBP), and hot gas defrosting (MBP, LBP).
All Blocksystems are equipped with:
Self-supporting casing in zinc-plated metal sheet, which is coated with epoxy powder and easily removable panels for fast access to components during inspection or maintenance operations
Hermetic or semi hermetic compressors with thermal motor protection
Heat exchangers with aluminium fins and copper coils
Direct gas expansion with capillary tube or thermostatic expansion valve (optional where not fitted as standard)
Air cooled condenser (optional condensation by water)
Automatic defrosting with programmable run, duration and frequency settings
Integral evaporating condensing water tray, or condensing water direct discharge
SFM008 G001 Rivacold Ceiling Mounted Chiller 1ph 1288w Duty - Coldroom Max Volume 9.5m3 Downloads
